Product Description
AMD Ryzenâ„¢ 7 9800X3D Desktop Processor
8 Cores | 16 Threads | Zen 5 Architecture | 3D V-Cache™ Technology | PCIe® 5.0 | DDR5 Support | Radeon™ Graphics
The AMD Ryzen™ 7 9800X3D is the ultimate gaming processor, designed to deliver unmatched speed and responsiveness for the most demanding titles. Built on AMD’s advanced Zen 5 architecture and featuring 2nd generation AMD 3D V-Cache™ technology, it delivers up to 96MB of L3 cache for ultra-low latency, faster frame rates, and smoother gameplay across every genre.
Whether you're gaming, creating, or multitasking, the Ryzen™ 7 9800X3D offers elite desktop performance with the efficiency and precision expected from AMD’s newest generation of processors.
 Key Features
8 Cores & 16 Threads
Base Clock: 4.7 GHz
Max Boost Clock: Up to 5.2 GHz
96MB AMD 3D V-Cacheâ„¢ for ultra-fast gaming
Zen 5 Architecture (TSMC 4nm FinFET process)
Integrated AMD Radeonâ„¢ Graphics
DDR5 Dual-Channel Memory Support (up to 192GB)
PCIe® 5.0 Support
Unlocked for Overclocking
Precision Boost 2 & Precision Boost Overdrive
AMD EXPOâ„¢ Memory Overclocking Technology
AMD Ryzenâ„¢ Master Utility Support
 Performance Engineered for Gaming Excellence
The Ryzen™ 7 9800X3D redefines what’s possible in PC gaming with its revolutionary stacked 3D cache design, allowing data to be accessed faster than ever before. This means improved frame pacing, reduced latency, and superior performance in CPU-intensive games like strategy, simulation, and competitive shooters.
Built using the Zen 5 microarchitecture, this processor achieves remarkable gains in single-threaded performance and efficiency over Zen 4, giving gamers and creators alike the edge in both speed and responsiveness.
 Thermal and Power Efficiency
Featuring a 120W TDP and fabricated using TSMC’s 4nm process, the 9800X3D balances raw power with exceptional energy efficiency. AMD recommends using a high-performance liquid cooler for optimal sustained performance and thermal control under heavy workloads.
 Advanced Connectivity
With PCIe® 5.0 support and DDR5 memory, the Ryzen 7 9800X3D enables cutting-edge bandwidth for next-generation GPUs, NVMe SSDs, and peripherals — delivering faster load times, smoother multitasking, and future-proof expandability.
Its integrated AMD Radeonâ„¢ Graphics provides solid visual output for system setup, troubleshooting, or light workloads without needing a dedicated GPU.
 Specifications
| Category | Details |
| Name | AMD Ryzenâ„¢ 7 9800X3D |
| Family / Series | Ryzen / Ryzen 9000 Series |
| Architecture | Zen 5 |
| Codename | Granite Ridge (AM5) |
| Cores / Threads | 8 / 16 |
| Base Clock | 4.7 GHz |
| Max Boost Clock | Up to 5.2 GHz |
| L1 Cache | 640 KB |
| L2 Cache | 8 MB |
| L3 Cache | 96 MB (3D V-Cacheâ„¢) |
| TDP | 120W |
| Unlocked for Overclocking | Yes |
| Processor Technology | TSMC 4nm FinFET |
| I/O Die Process | TSMC 6nm FinFET |
| Socket | AM5 |
| Supported Chipsets | A620, B650, B650E, X670, X670E, X870, X870E, B840, B850 |
| PCIe® Version | PCIe® 5.0 (28 Total / 24 Usable Lanes) |
| Memory Type | DDR5 (Dual Channel) |
| Max Memory Capacity | 192GB |
| Memory Speeds | Up to DDR5-5600 (2x1R / 2x2R), DDR5-3600 (4x1R / 4x2R) |
| ECC Memory Support | Yes (Motherboard Dependent) |
| Integrated Graphics | AMD Radeonâ„¢ Graphics (2 Cores, 2200 MHz) |
| Display Output | USB Type-C® DisplayPort™ Alt Mode |
| Recommended Cooler | Liquid Cooler (not included) |
| Operating Systems Supported | Windows 11/10 64-bit, RHEL x86 64-bit, Ubuntu x86 64-bit |
| Max Operating Temperature (Tjmax) | 95°C |
| Product ID | 100-100001084 (Tray) |
