Product Description
AMD Ryzenâ„¢ 9 9950X AM5 Desktop Processor | 100-100001277WOF
Elite Performance for Gamers, Creators & AI Workloads
The AMD Ryzenâ„¢ 9 9950X is built for the most demanding users who need top-tier multitasking, ultra-fast content creation, and cutting-edge gaming performance. Powered by the new Zen 5 architecture, it combines 16 cores and 32 threads with a base clock of 4.3 GHz and a boost clock up to 5.7 GHz, delivering incredible power for any task.
Featuring a refined 4 nm process and a massive 64 MB L3 cache, this processor offers superior efficiency and lightning-fast response times. It supports the latest DDR5 memory, PCIe® 5.0, and AMD EXPO™ overclocking, making it a future-ready choice for high-end systems.
With integrated AMD Radeonâ„¢ Graphics, you can enjoy smooth visuals out of the box for setup and productivity, while its optimized power draw and thermal design ensure stable operation under heavy workloads.
 Key Features
16 Cores / 32 Threads – Massive multitasking for gaming, streaming & content creation.
Up to 5.7 GHz Max Boost Clock – Exceptional speed for demanding applications.
64 MB L3 Cache – Quick data access for reduced latency and higher frame rates.
Zen 5 Architecture – Enhanced IPC and power efficiency on the TSMC 4 nm process.
DDR5 & PCIe® 5.0 Support – Future-proof bandwidth and data performance.
Unlocked for Overclocking – Fine-tune power and performance via Precision Boost Overdrive.
Integrated AMD Radeon™ Graphics – Smooth display setup without a dedicated GPU.
Recommended Cooling – Liquid cooler advised for optimal thermal performance.
Â
 Specifications
| Category | Details |
| Model | AMD Ryzenâ„¢ 9 9950X |
| Socket | AM5 |
| Architecture | Zen 5 (4 nm CPU / 6 nm I/O Die) |
| Cores / Threads | 16 / 32 |
| Base Clock | 4.3 GHz |
| Max Boost Clock | Up to 5.7 GHz |
| L1 / L2 / L3 Cache | 1.28 MB / 16 MB / 64 MB |
| TDP | 170 W |
| Unlocked for Overclocking | Yes |
| Memory Type | DDR5 (Up to 5600 MHz) |
| Max Memory Capacity | 192 GB |
| Memory Channels | Dual Channel |
| ECC Support | Yes (Requires motherboard support) |
| PCI Express® Version | PCIe® 5.0 (28 Total Lanes / 24 Usable) |
| NVMe Support | Boot, RAID 0/1/5/10 |
| Integrated Graphics | AMD Radeonâ„¢ Graphics (2 Cores, 2200 MHz) |
| Display Support | USB Type-C DisplayPortâ„¢ Alt Mode, HDMI |
| Max Operating Temperature (Tjmax) | 95 °C |
| Recommended Cooler | Liquid Cooling Solution (PIB not included) |
| Supported Chipsets | A620, B650/E, X670/E, X870/E |
| OS Support | Windows 11/10 (64-bit), RHEL, Ubuntu |
| Product Type | Boxed Processor (WOF) |
