Product Description
AMD Ryzen™ Threadripper™ PRO 7965WX sTR5 Processor – 24 Cores | 48 Threads | 5.3 GHz Boost | 128 MB Cache | DDR5 ECC | PCIe 5.0 | 100-100000885WOF
Unmatched Professional Power for Workstations
The AMD Ryzen Threadripper PRO 7965WX redefines workstation performance for creators, engineers, and developers who demand absolute reliability and computational power.
Featuring 24 Zen 4 cores and 48 threads, this processor delivers enterprise-grade efficiency, security, and scalability through AMD PRO Technologies. With 5.3 GHz boost speeds, 8-channel DDR5 ECC support, and 128 PCIe 5.0 lanes, it accelerates even the most complex workloads — from simulation and design to AI computation and media rendering.
Key Features
24 Cores & 48 Threads
4.2 GHz Base / 5.3 GHz Max Boost Clock
128 MB L3 Cache + 24 MB L2 Cache
Eight-Channel DDR5 ECC Memory (up to 5200 MT/s)
128 PCIe 5.0 Lanes for High-Speed Expansion
AMD PRO Security & Manageability Suite
Precision Boost 2 & Precision Boost Overdrive
Built on TSMC 5 nm Zen 4 Architecture
Ideal for CAD, 3D Rendering, Simulation & AI Workflows
Specifications
| Category | Specification |
| Platform | Desktop / Workstation |
| Product Family | AMD Ryzen™ PRO Processors |
| Product Line | AMD Ryzen™ Threadripper™ PRO 7000 WX-Series |
| Architecture Codename | “Storm Peak” – Zen 4 |
| Cores / Threads | 24 / 48 |
| Base Clock | 4.2 GHz |
| Max Boost Clock | Up to 5.3 GHz |
| L1 Cache | 1.5 MB |
| L2 Cache | 24 MB |
| L3 Cache | 128 MB |
| Default TDP | 350 W |
| Fabrication Process | TSMC 5 nm (Cores) / 6 nm (I/O Die) |
| Unlocked for Overclocking | Yes |
| Socket Type | sTR5 |
| Supported Chipsets | WRX90, TRX50, Pro 695 |
| Memory Type | DDR5 ECC RDIMM |
| Memory Channels | 8 |
| Max Memory Speed | Up to 5200 MT/s |
| ECC Support | Yes (Default Enabled) |
| PCI Express® Version | PCIe 5.0 |
| PCIe Lanes (Total / Usable / Gen 5) | 148 / 144 / 128 |
| NVMe Support | Boot, RAID 0/1/5/10 |
| Thermal Solution | Not Included (requires high-performance cooler) |
| Max Operating Temp (Tjmax) | 95 °C |
| Launch Date | October 19, 2023 |
| OS Support | Windows 11 / 10 64-bit, RHEL x86 64-bit, Ubuntu x86 64-bit |
| Integrated Graphics | None – Discrete GPU Required |
| AMD Technologies | EXPO™, Precision Boost 2, PBO, Curve Optimizer |
| Security & Manageability | AMD PRO Security, Memory Guard, Secure Processor, DASH Support |
| Product ID | 100-100000885WOF |
