Product Description
AMD Ryzenâ„¢ Threadripperâ„¢ PRO 9965WX sTR5 Processor | 100-100000724WOF
Designed to Deliver. Built for Breakthroughs.
The World’s Fastest Workstation Processor
Unleash exceptional workstation performance with the AMD Ryzenâ„¢ Threadripperâ„¢ PRO 9965WX, engineered for professionals who demand uncompromised power, stability, and security. Featuring 24 Zen 5 cores and 48 threads, this processor is purpose-built for advanced workloads like CAD modeling, 3D rendering, AI simulation, data analysis, and high-end content creation.
With base clocks of 4.2 GHz and boost speeds up to 5.4 GHz, it delivers astonishing single- and multi-threaded performance across demanding professional software. Its 350 W TDP, 128 MB of L3 cache, and 8-channel DDR5 memory support ensure unparalleled throughput for the most intensive multitasking environments.
 Professional-Grade Performance
Built on AMD’s Zen 5 architecture and manufactured using the TSMC 4 nm process, the Threadripper PRO 9965WX provides optimal efficiency, low latency, and massive parallel power.
Paired with WRX90 chipset motherboards, it enables up to 128 PCIe 5.0 lanes for maximum expandability—ideal for large GPU arrays, fast NVMe RAID storage, and multi-I/O professional setups.
 AMD PRO Technologies for Secure Workflows
Stay protected with AMD Memory Guard, Secure Boot, and Firmware TPM, ensuring encryption-based security at the hardware level. AMD PRO Manageability allows enterprise-class remote management, perfect for IT-driven organizations handling sensitive engineering or creative projects.
 Key Features
24 Cores / 48 Threads with Zen 5 architecture
4.2 GHz Base Clock / Up to 5.4 GHz Boost Clock
128 MB L3 Cache + 24 MB L2 Cache for high-speed data access
8-Channel DDR5 memory support up to 6400 MT/s
PCIe 5.0 (148 lanes total / 128 usable) for ultimate expandability
Unlocked for overclocking with AMD EXPOâ„¢ and Precision Boost Overdrive
AMD PRO Security Suite and DASH Manageability for enterprise environments
Discrete GPU Required – optimized for workstations and render nodes
350 W TDP with recommended liquid cooling
Â
 Specifications
| Category | Details |
| Model | AMD Ryzenâ„¢ Threadripperâ„¢ PRO 9965WX |
| Architecture | Zen 5 |
| Cores / Threads | 24 / 48 |
| Base Clock / Boost Clock | 4.2 GHz / Up to 5.4 GHz |
| L1 / L2 / L3 Cache | 1920 KB / 24 MB / 128 MB |
| TDP | 350 W |
| Socket | sTR5 |
| Process Technology | TSMC 4 nm (CPU) / 6 nm (I/O Die) |
| Unlocked | Yes |
| Memory Type | DDR5 RDIMM |
| Memory Channels | 8 |
| Max Memory Speed | Up to 6400 MT/s |
| Max Memory Capacity | Dependent on motherboard configuration |
| ECC Support | Yes (Default Enabled) |
| PCI Express Version | PCIe 5.0 (148 lanes total / 128 usable) |
| NVMe Support | Boot, RAID 0/1/5/10 |
| Integrated Graphics | Discrete GPU Required |
| Supported Chipsets | WRX90, TRX50, Pro 695 |
| Operating Systems | Windows 11/10 (64-bit), RHEL, Ubuntu |
| Max Temperature (Tjmax) | 95 °C |
| Thermal Solution (PIB) | Not Included – Liquid cooler recommended |
| Security Features | Memory Guard, Secure Boot, Firmware TPM, Device Guard, VBS, AES-NI |
| Manageability | AMD DASH Support – Yes |
