CH-2608TX

UHD+ Multi-Format to HDBaseT Switcher

• HDBaseT output supports resolutions up to 4K@60Hz (4:2:0, 8-bit) with automatic down conversion to 1080p for any sources that exceed HDBaseT’s bandwidth limitations, such as 4K@60Hz (4:4:4, 8-bit) or 4K@any (10/12-bit) sources

• Supported HDBaseT feature set: HD Video & Audio, PoH (PD), and Control Extension (Bi-directional IR/RS-232/USB)

• Analog audio may be embedded with all sources

• USB Type-C input can provide power (up to 60W) to any connected device (only available when the unit is powered locally)

• Supports manual input selection or automatic input selection with hot plug detection

• Basic signal event automation (via RS-232 or CEC)

• Supports optionally being powered via PoH from a compatible HDBaseT receiver

• Controllable via front panel button, WebGUI, Telnet, or RS-232
