CH-507TXBD CAT5e/6 to HDMI Extender delivers stable 4K@60 transmission up to 70m with LAN, IR, RS-232, HDCP support, and rich audio pass-through for pro AV systems. CH-507TXBD

CH-507TXBD

CAT5e/6 to HDMI with LAN/IR/RS-232 (4K@60 420 up to 70M)

• RS-232 with baud rate up to 115200/sec
• Supports wide range of IR frequency from 30~50kHz
• Supports HDMI 3D and 4K x 2K features
• Supports HDCP repeater and CEC bypass
• Supports pass-through of audio formats including LPCM 2.0/5.1/7.1, Bitstream and HD Bitstream over HDMI
• Supports pass-through of audio formats including LPCM 2.0/5.1/7.1, and Bitstream over HDMI
• HDBaseT™ convergence: uncompressed high-defi nition Video and Audio, LAN serving, Bi-directionlal Power over Cable (PoC) and IR/RS-232 Control pass-through
