Product Description
ASUS 90DA00L3-B09000 ASUS Prime MR120 ARGB Reverse Fan 120mm PWM, Dual-Sided Lighting, 28mm Thick Frame, Aura Sync Compatible
Illuminate Every Angle.
The ASUS Prime MR120 ARGB Reverse Fan is specifically designed for intake positions (such as bottom or side mounts), allowing you to maintain a cohesive look in your build by showing the clean face of the fan while effectively drawing in cool air.
Key Performance Features:
Extra-Thick 28mm Frame: Compared to standard 25mm fans, the increased thickness provides a sturdier foundation and improved cooling performance by allowing for a more optimized blade structure.
Dual-Sided ARGB Aesthetics: Featuring 20 addressable RGB LEDs in a striking circular design, the dual-sided lighting on the frame creates a seamless, vibrant aesthetic that looks professional from any viewing angle.
Intelligent Control & Quiet Operation: With PWM control up to 1600 RPM, you can create custom fan curves to balance quiet operation during light workloads with maximum airflow when gaming. It maintains a low noise profile (up to 23 dB(A)) even under load.
Easy Synchronization: Fully compatible with ASUS Aura Sync, enabling you to coordinate lighting colors and effects across your motherboard, GPU, and other compatible hardware with ease.
Technical Specifications
| Feature | Specification |
| Fan Size | 120 x 120 x 28 mm |
| Blade Orientation | Reverse (Optimized for Intake) |
| Fan Speed | 1600 RPM (+/- 10%) |
| Airflow | 58 CFM |
| Static Pressure | 1.38 mm H2O |
| Noise Level | 23 dB(A) |
| Bearing Type | Sleeve Bearing |
| Lighting | 20x ARGB LEDs (Aura Sync Compatible) |
| Connector | 4-pin PWM |
| Operating Voltage | 12V |
