CPLUS-V11PE2 UHD+ HDMI Audio Extractor delivers high-bandwidth 4K@60Hz pass-through with flexible analog and optical audio extraction, advanced EDID control, and pro-grade AV reliability. CPLUS-V11PE2

CPLUS-V11PE2

UHD+ HDMI Audio Extractor

• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compatible with the use of an HDMI-DVI adaptor
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3840×2160@60 Hz (4:4:4, 8-bit) & 4096×2160@60 Hz (4:4:4, 8-bit)
• Supports 48-bit Deep Color up to 1080p@60Hz
• Supports passthrough of LPCM 7.1, Bitstream and HD Bitstream audio formats over HDMI
• Analog audio extraction supports LPCM 2.0 sources
• Optical S/PDIF audio extraction supports LPCM 2.0 & Bitstream formats
• Supports HDMI and S/PDIF audio sampling rates up to 192kHz
• Provides EDID management with EDID bypass and 2 user modifiable EDIDs
• PC based EDID management tool support
• Supports RS-232 style control via a Virtual COM port over USB
