CPLUS-V11PI UHD+ HDMI Audio Inserter adds analog or S/PDIF audio to 4K@60 HDMI with 18Gbps pass-through, advanced EDID control, and pro AV reliability. CPLUS-V11PI

CPLUS-V11PI

4K UHD+ HDMI Audio Inserter

• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compatible with the use of an HDMI-DVI adaptor
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3840×2160@60 Hz (4:4:4, 8-bit) & 4096×2160@60 Hz (4:4:4, 8-bit)
• Supports 48-bit Deep Color up to 1080p@60Hz
• Supports passthrough of LPCM 7.1, Bitstream and HD Bitstream audio formats over HDMI
• Supports embedding external audio sources (analog stereo or digital S/PDIF) into an existing HDMI source, or adding audio to a DVI source (output as HDMI)
• Supports HDMI audio sampling rates up to 192kHz
• Supports the following S/PDIF audio sampling rates: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 192kHz
• Provides EDID management with EDID bypass and 2 user modifiable EDIDs
• PC based EDID management tool support
• Outputs a 720p60 color bar pattern when no input is connected
• Supports RS-232 style control via a Virtual COM port over USB
