CPLUS-V4H4HPA UHD+ 4×4 Matrix delivers high-bandwidth 4K@60Hz switching with advanced audio pass-through, rich EDID options, OSD, and full control via WebGUI, RS-232, and IR. CPLUS-V4H4HPA

CPLUS-V4H4HPA

UHD+ 4x4 Matrix with Audio Output

• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compliant with the use of an HDMI-DVI adaptor
• Supports HD resolutions up to 3840x2160@60 Hz (YUV 4:4:4, 8-bit) & 4096x2160@60 Hz (YUV 4:4:4, 8-bit)
• Supports 16-bit Deep Color up to 1080p60
• Supports pass-through of LPCM 7.1, bitstream and HD bitstream audio formats
• Supports six internal EDIDs, four external EDIDs copied from connected devices, and four user provided EDIDs
• OSD with user customizable information text
• Intuitive control interface including telnet, WebGUI, OSD, IR remote and RS-23
