Product Description
GIGABYTE B760M Gaming X WIFI6E GEN5 – Premium Gaming Power in mATX
The GIGABYTE B760M Gaming X WIFI6E GEN5 is a high-end Micro-ATX motherboard built for Intel® 12th, 13th, and 14th Gen processors, delivering next-generation PCIe 5.0 performance, full-capacity DDR5 memory, and ultra-fast Wi-Fi 6E connectivity in a compact, battle-ready design.
Designed for serious gamers and power users, it supports up to 256GB of DDR5 memory across four DIMM slots, enabling smooth multitasking, high frame rates, and long-term upgrade flexibility. The PCIe 5.0 x16 slot ensures compatibility with next-gen graphics cards, while dual PCIe 4.0 M.2 slots deliver blazing-fast NVMe storage performance.
With Intel® Wi-Fi 6E + Bluetooth 5.3, 2.5Gb Ethernet, advanced cooling headers, rich RGB support, and GIGABYTE’s proven BIOS tools including Q-Flash Plus, this motherboard is built to perform today—and stay relevant for years.
Key Highlights
Intel® LGA1700 support for 12th / 13th / 14th Gen CPUs
PCIe 5.0 x16 slot for next-generation GPUs
4× DDR5 DIMM slots – up to 256GB, XMP & OC support
DDR5 speeds up to 7600 MT/s (OC)
2Ă— PCIe 4.0 M.2 slots for ultra-fast NVMe SSDs
Intel® Wi-Fi 6E + Bluetooth 5.3
2.5GbE LAN for high-speed wired networking
Advanced RGB & cooling headers for gaming builds
Q-Flash Plus – update BIOS without CPU, RAM, or GPU
Specifications
| Category | Details |
| CPU | LGA1700 socket – Supports Intel® 14th / 13th / 12th Gen Core™, Pentium® Gold, Celeron® |
| Chipset | Intel® B760 Express |
| Memory | 4× DDR5 DIMM, up to 256GB, Dual Channel DDR5 4000–7600 MT/s (OC) ECC / Non-ECC Unbuffered, XMP support |
| Graphics | Intel® HD Graphics (CPU dependent) HDMI 2.1: 4K@60Hz DisplayPort 1.2: 4K@60Hz HDCP 2.3 |
| Audio | Realtek® HD Audio CODEC, 2/4/5.1/7.1-channel, S/PDIF Out |
| LAN | Realtek® 2.5GbE LAN (2.5G / 1G / 100Mbps) |
| Wireless | Intel® Wi-Fi 6E AX210 (2.4 / 5 / 6 GHz, 160MHz), Bluetooth 5.3 |
| Expansion Slots | 1Ă— PCIe 5.0 x16 (CPU) 1Ă— PCIe 3.0 x4 (Chipset) |
| Storage | 2Ă— M.2 PCIe 4.0 x4/x2 (2280 / 22110) 4Ă— SATA 6Gb/s RAID 0 / 1 / 5 / 10 |
| USB Ports | USB-C 3.2 Gen 2 (internal) USB 3.2 Gen 1 (rear & internal) USB 2.0 (rear & internal) |
| Internal I/O | 24-pin ATX, 8-pin CPU power CPU + 3Ă— system fan headers 3Ă— ARGB Gen2 + 1Ă— RGB header TPM, Thunderbolt add-in headers Q-Flash Plus, Clear CMOS |
| Back Panel I/O | HDMI, DisplayPort, USB ports, 2.5Gb LAN, audio jacks, Wi-Fi antennas |
| BIOS | 256 Mbit AMI UEFI BIOS, Q-Flash & Q-Flash Plus |
| OS Support | Windows® 11 / Windows® 10 (64-bit) |
| Form Factor | Micro-ATX (24.4 Ă— 24.4 cm) |
