HUAWEI CloudLink Bar 310 Integrated Ultra-HD Video Conferencing Endpoint
CloudLink Bar 310 is Huawei's next-generation integrated ultra-HD video conferencing endpoint running HarmonyOS with a built-in camera, microphone array, and HD codec, as well as a "smart eye" and full-HD PTZ camera (a dual-lens design) that features up to 12x optical zoom, to ensure that the speaker is always centered within the frame. The Bar 310 comes with a 1080p HD display, and is ideal for small and medium-sized meeting rooms.
High Security and Reliability
• Powerful performance, backed by HarmonyOS, proprietary core technologies, and a high-computing hardware platform.
• End-to-end encryption and media, as well as signaling encryption measures, such as H.235 and SRTP/TLS, to keep meetings safe and secure.
Integrated Design
• Integrated and minimalist design, with a built-in camera, microphone, and high-definition codec, for effortless cabling and easy installation.
• Ultra-high precision PTZ that rotates swiftly, precisely, and steadily, with a maximum deviation of just 0.1° in both horizontal and vertical directions.
• Six omnidirectional digital microphones, with a wide frequency range of 100 Hz to 20 kHz and an accurate 8-meter pickup, delivering exceptionally crisp and natural voices.
HD Video and Auto-Framing
• Auto-Framing: "Smart eye" keeps attendees centered within the frame, thanks to panoramic face detection and optical zoom of the main lens.
• 1080p60@H.265 HD codec, video 30% PLC.
• Huawei's proprietary VME technology removes noise from motion images, for enhanced video quality.
Specifications
|
| Parameters | Bar 310 |
| Full-HD main lens | 12X optical zoom |
| Multimedia framework protocols | ITU-T H.323、IETF SIP |
| Video codec protocols | H.265、H.265 SVC、H.264 HP、H.264 BP、H.264 SVC、H.263、H.263+ |
| Audio codec protocols | OPUS、AAC-LD、G.729A、G.722、G.722.1C、G.711U、G.711A |
| Video Features | Video Resolution：
1080p 60fps，1080p 30fps，720p 60fps，720p 30fps
Dual-stream Resolution:
1080P30 + 1080P30（4K8）
1080P60 + 1080P60（4K15） |
| Audio Input | Built-in microphone array、1×3.5mm、1×HD-AI、1×HDMI（audio）、1×Type-C（audio） |
| Audio Output | 1×3.5mm、1×HDMI（audio） |
| Video Input | 1×built-in camera、1×HDMI、1×Type-C |
| Video Output | 2×HDMI |
| Other Ports | 1×USB 3.0 Type-A、1×RJ45（10/100/1000M LAN）、1×RJ45（for Touch）、1×Wi-Fi（built-in） |
