Product Description
Intel Core i7-13700K 13th Gen Raptor Lake Desktop Processor | BX8071513700K
Experience next-level performance for gaming, content creation, and multitasking with the Intel Core i7-13700K, part of Intel’s 13th Generation Raptor Lake lineup. Featuring 16 cores and 24 threads with a hybrid architecture, this unlocked desktop CPU combines efficiency and raw power to deliver elite responsiveness and versatility for demanding workloads.
️ Key Features
16 Cores (8 Performance + 8 Efficient)
24 Threads for High Parallel Performance
Base Clock: 3.4 GHz (P-Cores) / 2.5 GHz (E-Cores)
Max Turbo Boost Frequency: Up to 5.4 GHz
30MB Intel Smart Cache (L3)
Supports DDR5-5600 / DDR4-3200 Dual-Channel Memory
Integrated Intel UHD 770 Graphics (Xe Architecture)
Unlocked for Overclocking
PCIe 5.0 & 4.0 Support (20 Lanes Total)
LGA 1700 Socket – Compatible with Intel 600 & 700 Series Chipsets
125W TDP (Base Power)
ECC Memory Support
No Cooler Included (Aftermarket Cooling Recommended)
Windows 11 Ready
Performance Overview
Hybrid Core Architecture
The i7-13700K uses Intel’s Hybrid Architecture, combining:
8 Performance-cores (P-cores): Optimized for demanding single-threaded workloads such as gaming and content creation.
8 Efficient-cores (E-cores): Designed for background or parallel tasks, ensuring smooth multitasking and lower power consumption.
Together, these cores deliver exceptional responsiveness and balance between speed and efficiency.
Intel Thread Director
This intelligent feature ensures each of the 24 threads is dynamically assigned to the most suitable core in real time — maximizing performance and maintaining energy efficiency across workloads.
PCIe 5.0 + DDR5 Support
Enjoy next-generation data transfer speeds with PCIe Gen 5 and DDR5-5600 MHz memory support (while retaining compatibility with DDR4-3200). Perfect for high-performance GPUs, NVMe SSDs, and next-gen components.
Integrated Graphics
The Intel UHD Graphics 770, powered by Xe architecture, offers support for 8K (7680x4320) and up to four simultaneous 4K displays — perfect for productivity setups, media editing, or testing systems without a discrete GPU.
AI & Acceleration Technologies
Intel Deep Learning Boost (DL Boost) accelerates AI inference workloads.
Gaussian & Neural Accelerator 3.0 (GNA) improves background noise suppression and visual clarity during calls.
Overclocking-Ready
With its unlocked multiplier, enthusiasts can push both P-cores and E-cores beyond stock speeds using Intel Extreme Tuning Utility (XTU) or BIOS-level adjustments.
Specifications
| Category | Details |
| Processor Model | Intel Core i7-13700K (13th Gen Raptor Lake) |
| Socket Type | LGA 1700 |
| Architecture | Intel 7 (Raptor Lake Hybrid Architecture) |
| Total Cores | 16 (8P + 8E) |
| Total Threads | 24 |
| Base Clock (P-Cores) | 3.4 GHz |
| Base Clock (E-Cores) | 2.5 GHz |
| Max Turbo Frequency (P-Cores) | 5.3 GHz |
| Max Turbo Frequency (E-Cores) | 4.2 GHz |
| Intel Turbo Boost Max 3.0 | Up to 5.4 GHz |
| Cache (L3) | 30 MB Intel Smart Cache |
| Memory Support | DDR5 up to 5600 MHz / DDR4 up to 3200 MHz |
| Max Memory Capacity | 128 GB |
| Memory Channels | 2 (Dual Channel) |
| ECC Memory Support | Yes |
| PCI Express Support | PCIe 5.0 (16 lanes) + PCIe 4.0 (4 lanes) |
| Total PCIe Lanes | 20 |
| Optane Memory Support | Yes |
| Integrated Graphics | Intel UHD Graphics 770 |
| Graphics Base Clock | 300 MHz |
| Graphics Boost Clock | 1.45 GHz |
| Max Resolution (HDMI) | 4096 x 2160 @ 60Hz |
| Max Resolution (DP) | 7680 x 4320 @ 60Hz |
| Display Support | Up to 4 displays |
| Supported APIs | DirectX 12, OpenGL 4.5 |
| TDP (Base Power) | 125 W |
| Max Turbo Power | 253 W |
| Cooling Solution | Not Included |
| Max Temperature (TJUNCTION) | 100°C |
| Virtualization | Intel VT-x, VT-d, and EPT |
| Security Features | AES-NI, Boot Guard, OS Guard, Control-Flow Enforcement (CET), TDT, Secure Key |
| Performance Technologies | Turbo Boost 2.0 / Max 3.0, Hyper-Threading, Deep Learning Boost, SpeedShift, Thread Director |
| Chipset Compatibility | Intel 600 / 700 Series |
| Operating System Support | Windows 10 / 11 (64-bit) |
| Launch Status | Launched |
