Product Description
Intel Core i7-13700KF 13th Gen Raptor Lake Desktop Processor | BX8071513700KF
Unleash elite performance and efficiency with the Intel Core i7-13700KF, a powerhouse 13th Generation processor built for gamers, creators, and professionals who demand uncompromised speed. Featuring 16 cores, 24 threads, and a 5.4 GHz max turbo frequency, this unlocked CPU delivers exceptional multitasking, gaming, and productivity performance—all while supporting the latest DDR5 memory and PCIe 5.0 technology.
Key Features
16 Cores (8 Performance + 8 Efficient)
24 Threads for Smooth Multitasking
Base Clock: 3.4 GHz (P-Cores) / 2.5 GHz (E-Cores)
Max Turbo Boost Frequency: Up to 5.4 GHz
30MB Intel Smart Cache (L3)
Unlocked Multiplier for Overclocking
Supports DDR5-5600 / DDR4-3200 Dual-Channel Memory
PCIe 5.0 & 4.0 Support (20 Lanes Total)
LGA 1700 Socket – Compatible with Intel 600 & 700 Series Chipsets
125W Base Power / 253W Max Turbo Power
No Integrated Graphics – Dedicated GPU Required
Windows 11 Ready
 Performance Overview
 Hybrid Core Architecture
The Raptor Lake architecture combines two specialized core types to maximize efficiency and speed:
Performance-cores (P-cores): Designed for high-demand, single-threaded tasks like gaming and creative workloads.
Efficient-cores (E-cores): Handle background operations and multitasking with minimal power consumption.
Together, they deliver lightning-fast responsiveness and superior multitasking ability.
 Intel Thread Director
Built directly into the CPU, the Intel Thread Director intelligently distributes tasks across cores, ensuring optimal performance by dynamically assigning threads to the most suitable cores.
 PCIe 5.0 & DDR5 Support
Experience next-generation speeds with PCIe Gen 5.0 for GPUs and SSDs, and DDR5-5600 MHz memory support for ultra-fast data throughput. Backward compatibility with DDR4-3200 ensures flexibility for various system builds.
 AI & Performance Enhancements
Intel Deep Learning Boost (DL Boost): Accelerates AI workloads and inference performance.
Gaussian & Neural Accelerator 3.0 (GNA): Enhances background noise suppression and visual clarity during communication or streaming.
 Unlocked for Overclocking
Fine-tune performance to your exact needs with Intel’s Extreme Tuning Utility (XTU) or motherboard-level BIOS controls—giving enthusiasts complete control over both P-cores and E-cores.
Specifications
| Category | Details |
| Processor Model | Intel Core i7-13700KF (13th Gen Raptor Lake) |
| Socket Type | LGA 1700 |
| Architecture | Intel 7 (Hybrid Core Design) |
| Total Cores | 16 (8P + 8E) |
| Total Threads | 24 |
| Base Clock (P-Cores) | 3.4 GHz |
| Base Clock (E-Cores) | 2.5 GHz |
| Max Turbo Frequency (P-Cores) | 5.4 GHz |
| Max Turbo Frequency (E-Cores) | 4.2 GHz |
| Cache (L3) | 30 MB Intel Smart Cache |
| Memory Support | DDR5 up to 5600 MHz / DDR4 up to 3200 MHz |
| Max Memory Capacity | 128 GB |
| Memory Channels | 2 (Dual Channel) |
| ECC Memory Support | No |
| PCI Express Support | PCIe 5.0 (16 lanes) + PCIe 4.0 (4 lanes) |
| Total PCIe Lanes | 20 |
| Optane Memory Support | Yes |
| Integrated Graphics | None (Dedicated GPU Required) |
| TDP (Base Power) | 125 W |
| Max Turbo Power | 253 W |
| Thermal Solution | Not Included |
| Max Operating Temperature (TJUNCTION) | 100°C |
| Virtualization Support | Intel VT-x, VT-d, and EPT |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel SSE4.1, SSE4.2, AVX2, AVX-512 |
| Security Features | AES-NI, Boot Guard, OS Guard, Control-Flow Enforcement (CET), Trusted Execution, Secure Key, TDT |
| Performance Technologies | Turbo Boost 2.0 / Max 3.0, Hyper-Threading, Deep Learning Boost, SpeedShift, SpeedStep, Thread Director |
| Chipset Compatibility | Intel 600 / 700 Series |
| Operating System Support | Windows 10 / 11 (64-bit) |
| Launch Status | Launched |
