Product Description
LG 86UL3J 86" 4K UHD ADS Digital Signage Display | webOS 6.0 | Built-in Wi-Fi | 1.07 Billion Colors | Smart Energy Saving | Mount Included | Black
The LG 86UL3J is a professional-grade 4K UHD digital signage display engineered for stunning image clarity, smooth performance, and seamless wireless collaboration. Designed for meeting rooms, educational spaces, and business environments, it combines intelligent functionality with a sleek, durable build.
Featuring an expansive 86-inch ADS panel with 4K UHD (3840 × 2160) resolution and 1.07 billion colors, the 86UL3J delivers lifelike visuals and consistent brightness across a wide 178° viewing angle. Powered by LG webOS 6.0, it allows effortless content management, remote scheduling, and network-based control — all through an intuitive interface.
With LG One:Quick Share, users can wirelessly project their PC screens using a USB dongle and built-in Wi-Fi, eliminating cable clutter and enhancing collaboration. Integrated speakers, smart energy-saving mode, and 16/7 operation make it the ideal signage solution for corporate and educational applications.
Key Features
86" 4K UHD ADS Display (3840 × 2160) – Sharp, high-contrast images with wide viewing angles.
LG webOS 6.0 – Smart, secure platform for signage content management and remote control.
LG One:Quick Share – Wireless screen sharing via USB dongle and built-in Wi-Fi.
Vivid Color Accuracy – Advanced 8-bit + FRC processing for 1.07 billion colors.
Smooth Motion – 8 ms (G to G) response time for crisp playback and animations.
Smart Energy Saving – Up to 70% power reduction without image quality loss.
Durable and Versatile – 16/7 operation, portrait & landscape support, and VESA mount included.
Integrated Audio System – Built-in speakers for clean installation and professional sound.
Seamless Integration – Compatible with LG SuperSign CMS, Control+, WB, and ConnectedCare.
Specifications
| Category | Details |
| Model | LG 86UL3J |
| Display Size | 86" |
| Panel Technology | ADS (Advanced Super Dimension Switch) |
| Resolution | 3840 × 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Brightness (Typ.) | 330 nits |
| Contrast Ratio (Static / Dynamic) | 1,400:1 / 1,000,000:1 |
| Color Depth | Advanced 8-bit + FRC (1.07 Billion Colors) |
| Color Gamut | DCI 80% |
| Viewing Angle (H/V) | 178° / 178° |
| Response Time (G to G) | 8 ms |
| Surface Treatment (Haze) | 1% |
| Operation Hours | 16 hrs/day (Portrait & Landscape) |
| Operating System | LG webOS 6.0 |
| Wireless Connectivity | Built-in Wi-Fi (via One:Quick Share support) |
| Inputs | 3× HDMI (HDCP 2.2/1.4), 2× USB 2.0 Type-A |
| Outputs | Audio Out |
| External Control | RS-232C In/Out (4-Pin Phone Jack), RJ45 (LAN) |
| Speakers | Integrated Stereo Speakers |
| Bezel Color / Width | Ashed Blue / 6.9 mm (off), 15.9 mm (on) |
| Dimensions (W×H×D) | 1927 × 1104 × 59.9 mm |
| Carton Dimensions (W×H×D) | 2115 × 1215 × 228 mm |
| Weight (Net / Packed) | 45.2 kg / (TBD) |
| Handle | No |
| VESA Mount | 600 × 400 mm (Included) |
| Power Supply | AC 100–240 V ~ 50/60 Hz (Built-in) |
| Power Consumption (Typ./Max.) | TBD / TBD W (751–1024 BTU/hr) |
| Operating Temperature / Humidity | 0–40 °C / 10–80 % RH |
| Certifications | CB, FCC Class “A”, CE, ErP, ePEAT (US Only) |
| Software Compatibility | SuperSign CMS, Control+, WB, Media Editor, LG ConnectedCare |
| Included Accessories | Remote Control (2× Batteries), Power Cord, Cable Holder, RS-232 Gender Adapter, Regulation Book |
