Product Description
LG 98TR3DK CreateBoard, 98" 4K UHD IPS Touch Display, 60Hz Refresh Rate, 8ms Response Time, Quad-Core A55 CPU, Mali G52MP2 GPU, 64GB Storage, 8GB RAM, Max 40 Touch Points, Black | 98TR3DK
Overview
The LG 98TR3DK CreateBoard is a large-format interactive display designed for seamless collaboration and immersive learning. As part of LG’s advanced CreateBoard Series, it offers stunning 4K UHD visuals, ultra-responsive touch performance, and intelligent connectivity—making it ideal for classrooms, meeting rooms, and digital collaboration spaces.
Equipped with a Quad-Core A55 processor, 8GB RAM, and 64GB storage, the 98TR3DK ensures smooth operation for multitasking and real-time interaction. Its infrared 40-point multi-touch capability allows multiple users to interact simultaneously, while the IPS 4K panel delivers vivid and accurate colors from any angle.
Key Features
️ Massive 98-inch 4K UHD Display – Crisp visuals and vibrant color accuracy for presentations and lessons.
40-Point Multi-Touch (Windows) / 32-Point (Android) – Enables collaborative interactivity for multiple users.
️ High-Performance Processor – Quad-Core A55 with Mali G52MP2 GPU for smooth app performance.
Ample Memory and Storage – 8GB RAM and 64GB internal storage for faster operations and media handling.
True-to-Life Picture Quality – 440 nits max brightness, 1200:1 contrast ratio, and NTSC 72% color gamut.
Integrated 15W x 2 Stereo Speakers – Clear sound for interactive sessions or meetings.
Comprehensive Connectivity – HDMI, USB-C, VGA, LAN, RS232C, Optical SPDIF, and multiple USB ports.
Wireless Connectivity – WiFi 6 and Bluetooth 5.0 for seamless device pairing.
Android 13 OS Built-in – Intuitive, secure, and ready for educational and enterprise use.
Compatible with OPS Slot Modules – Expand computing power with plug-and-play modules.
Energy Efficient and Durable – Rated for 16/7 operation with ≤0.5W standby power.
Comes with Accessories – Includes writing pens, HDMI cable, USB-C cable, and remote control.
Specifications
| Category | Specification |
| Brand | LG |
| Model | 98TR3DK |
| Display Type | Interactive Digital Display |
| Screen Size | 98 inches |
| Panel Technology | IPS (Direct LED Backlight) |
| Aspect Ratio | 16:9 |
| Resolution | 3840 x 2160 (4K UHD) |
| Brightness (Max / Typ.) | 440 nits / 390 nits |
| Contrast Ratio | 1200:1 |
| Color Gamut | NTSC 72% |
| Color Depth | 10-bit (1.07 Billion Colors) |
| Viewing Angle (H/V) | 178° / 178° |
| Response Time | 8 ms |
| Surface Treatment | Anti-Glare (25% Haze) |
| Lifetime (Min / Typical) | 30,000 hrs (L50) / 50,000 hrs (L30) |
| Operation Hours | 16 hrs/day, 7 days/week |
| Orientation | Landscape only |
| Operating Temperature | 0°C – 40°C |
| Operating Humidity | 10% – 90% RH |
| Bezel Color | Black |
| Bezel Width (T/R/L/B) | 30 / 27 / 27 / 45 mm |
| Weight (Net / Packed) | 103.6 kg / 133.2 kg |
| Dimensions (W x H x D) | 2244 × 1323 × 91 mm |
| Carton Dimensions (W x H x D) | 2406 × 1474 × 280 mm |
| Handle | Yes |
| Mount Interface (VESA) | 800 × 600 mm |
| Power Supply | 100–240V AC, 50/60Hz |
| Power Consumption (Typ./Max) | 395W / 610W |
| Power Standby | ≤ 0.5W |
| BTU (Typ./Max) | 1348 / 2081 BTU/hr |
| Certification (Safety/EMC) | CB / NRTL / FCC Class A / CE / KC |
| Energy Compliance | ErP / ENERGY STAR Certified |
| OPS Compatibility | Yes, with Built-in OPS Power |
| Speakers | 15W x 2 (Stereo) |
| Touch Technology | Infrared |
| Touch Points | Max 40 (Windows) / 32 (Android) |
| Touch Object Size | ≥ 2 mm |
| Touch Accuracy | ±1.5 mm |
| Touch Response Time | ≤ 5 ms |
| Touch Interface | USB 2.0 |
| Protection Glass | 4T (Anti-Glare), 88% Transmission |
| Connectivity (Inputs) | HDMI (3), RGB (VGA), Audio In, RS-232C, RJ45, USB 3.0 (x4), USB 2.0 (x1), USB Type-C |
| Connectivity (Outputs) | HDMI Out, Audio Out, Optical SPDIF, Touch USB (x2), RJ45 |
| Android SoC | Quad-Core A55 |
| GPU | Mali G52MP2 |
| RAM / Storage | 8GB / 64GB |
| Operating System | Android 13 |
| WiFi | 802.11a/b/g/n/ac/ax (WiFi 6) |
| LAN | Gigabit Ethernet |
| Bluetooth | 5.0 |
| Included Accessories | Power cord, HDMI cable, USB-C cable, USB cable, Writing Pens (x2), Wi-Fi module, Remote, Manual, QSG |
| Optional Accessories | Wall Mount, Floor Stand |
