Product Description
MSI MAG PANO 110R PZ Mid-Tower PC Case – Black
The MSI MAG PANO 110R PZ redefines modern chassis design with its bold 270° panoramic glass layout, delivering an unobstructed showcase of your components from the front and side. Built for enthusiasts who want exceptional visibility, flexible hardware support, and powerful cooling performance, this mid-tower case combines clean aesthetics with high-end airflow engineering.
Equipped with four pre-installed ARGB fans, including three reverse-blade side fans for optimal intake and clean visual presentation, the MAG PANO 110R PZ ensures efficient cooling while highlighting your lighting effects. With support for up to 10 total fans and a 360mm top radiator, the case is ready for advanced air or liquid-cooled builds.
The tool-free panoramic glass panels provide premium durability and convenient access, while dual top and bottom dust filters maintain a clean system over time. The case supports both regular and back-connect motherboards, accommodating the latest hardware innovations and minimizing cable clutter. A modern I/O panel featuring 20Gbps USB Type-C ensures fast connectivity and an elevated building experience.
Designed for gamers, creators, and PC modders, the MAG PANO 110R PZ offers an exceptional balance of performance, style, and next-generation compatibility.
Specifications
| Category | Details |
| Product Name | MAG PANO 110R PZ |
| Case Form Factor | Mid-Tower |
| Motherboard Support | Regular: ATX / Micro-ATX / Mini-ITX Back-connect: ATX / Micro-ATX |
| I/O Ports | 1 × USB 20Gbps (Type-C) 2 × USB 5Gbps (Type-A) 1 × Audio-Out / Mic-in 1 × LED Button 1 × Power Button |
| Drive Support | 2 × 2.5" 2 × 3.5" 2 × 2.5"/3.5" combo |
| Expansion Slots | 7 |
| Maximum GPU Length | 400 mm / 15.75 in |
| Maximum CPU Cooler Height | 160 mm / 6.30 in |
| Power Supply Support | ATX |
| Maximum PSU Length | 200 mm / 7.87 in |
| Fan Support | Top: 3 × 120mm / 2 × 140mm Front: N/A Rear: 1 × 120mm Side: 3 × 120mm / 2 × 140mm Bottom: 3 × 120mm (above PSU shroud) |
| Pre-Installed Fans | Side: 3 × 120mm ARGB Reverse-Blade Rear: 1 × 120mm ARGB |
| Radiator Support | Top: 120 / 140 / 240 / 280 / 360 mm Front: N/A Rear: 120 mm Side: N/A Bottom: N/A |
| Dimensions (D × W × H) | 420 × 225 × 485 mm 16.54 × 8.86 × 19.09 in |
