Samsung VHC-R Series Video Wall – 55"

Key Highlights

• Screen Size: 55 inches

• Resolution: Full HD (1920 × 1080)

• Panel Type: IPS

• Bezel: Ultra-narrow 0.44 mm (even on all sides) – virtually seamless video wall setup

• Response Time: 8 ms

• Operation Time: 24/7 continuous use

• Special Feature: Advanced image enhancement technology

• Color: Black

Display Specifications

• Resolution: Full HD (1920 × 1080)

• Screen Size: 55″ diagonal

• Panel Technology: IPS (consistent colors and wide viewing angles)

• Brightness: 700 nits (typical – suited for well-lit indoor spaces)

• Contrast Ratio: 1200:1 (static)

• Dynamic Contrast: Mega Contrast

• Response Time: 8 ms (typical)

• Viewing Angles: 178° (H) / 178° (V)

• Color Gamut: 72% NTSC

• Haze Level: 28% (anti-glare, reduces reflections)

• Refresh Rate: 60 Hz

• Operation: Rated for 24/7 usage

Image Enhancement Features

• Uniformity Calibration: Factory-tuned for consistent brightness and color across all displays

• Color Adjustment: Advanced color calibration for seamless multi-screen installations

• Local Dimming: Improves contrast and black levels in darker scenes

• Image Enhancement Engine: Reduces noise and enhances detail for clarity

Connectivity & Ports

• HDMI: 2 × HDMI 2.0

• DisplayPort: 1 × DP 1.2 In, 1 × DP 1.2 Out (for daisy-chaining multiple displays)

• DVI-D: 1 input

• USB: 1 × USB 2.0 (for firmware/service)

• Audio: Stereo mini-jack (in/out)

• RS-232C (In/Out): Yes (for control & daisy chaining)

• RJ45 (LAN): Yes

• IR Input: Yes

Mechanical & Physical Specs

• Display Dimensions (W × H × D): ~1210.5 × 681.2 × 69.9 mm

• Bezel Width: 0.44 mm even (top, bottom, left, right)

• Package Dimensions: ~1350 × 850 × 200 mm

• Net Weight: ~21.5 kg

• Packaged Weight: ~27.5 kg

• Mounting Standard: VESA 600 × 400 mm

• Frame Color: Black, slim profile optimized for video wall setups

Power & Environmental

• Power Supply: AC 100–240V, 50/60Hz

• Power Consumption (On): ~150 W (typical)

• Power Consumption (Standby): <0.5 W

• Operating Temperature: 0°C to 40°C

• Operating Humidity: 10% to 80% (non-condensing)

Strengths

• Ultra-narrow 0.44 mm bezel enables nearly seamless video wall installations

• High brightness (700 nits) ensures vivid, sharp images in bright indoor environments

• 24/7 operation rating – reliable for critical signage and control rooms

• IPS panel provides consistent viewing from any angle with accurate colors

• Daisy-chain support (DP in/out) for large video wall setups

• Advanced calibration tools for uniform, professional-grade visuals

Considerations

• Requires professional mounting and calibration for best results

• Brightness (700 nits) is strong for indoor, but not sunlight-readable outdoors

• Needs careful cooling/ventilation in large video wall arrays

• Not designed for standalone consumer use – optimized for commercial video wall setups

Ideal Applications

• Control rooms and command centers

• Retail and shopping malls (large advertising walls)

• Corporate lobbies and auditoriums

• Airports, train stations, and transportation hubs

• Museums and exhibition halls

• Broadcasting studios and event backdrops
