Product Description
Samsung QB24C-T 24" Multi-Touch Smart Display (LH24QBCTBGCXUE)
The Samsung QB24C-T 24" Multi-Touch Smart Display is a compact, professional-grade screen designed for interactive retail, wayfinding, kiosks, control rooms, and corporate environments. Featuring a Full HD ADS panel, capacitive multi-touch technology, and 16/7 operation, it delivers clear visuals, wide viewing angles, and smooth responsiveness for continuous business use.
With built-in WiFi, Bluetooth, Tizen 7.0 OS, and a powerful system-on-chip, it supports smart signage applications without the need for an external media player. Its slim, non-glossy design makes it ideal for tight spaces and wall-mounted digital signage. Perfect for customer interaction points, digital menus, and commercial touch-based interfaces.
Specifications
| Category | Specification |
| Model | LH24QBCTBGCXUE |
| Diagonal Size | 23.8" |
| Panel Type | ADS |
| Resolution | 1920 × 1080 (FHD) |
| Pixel Pitch (H × V) | 0.2745 × 0.2745 mm |
| Brightness (Typical) | 250 nit (without glass) |
| Contrast Ratio | 1000:1 (without glass) |
| Dynamic Contrast Ratio | Mega |
| Viewing Angle (H/V) | 178° / 178° |
| Response Time | 14 ms |
| Colour Gamut | 72% NTSC |
| Glass Haze | 25% (without glass) |
| Operation Time | 16/7 |
| H-Scanning Frequency | 56 – 84.5 kHz |
| V-Scanning Frequency | 48 – 75 Hz |
| Maximum Pixel Frequency | 148.5 MHz |
| HDMI In | 1 × HDMI 1.4 |
| DP In | No |
| HDCP Version | 2.2 |
| USB Ports | 1 |
| IR In | Yes |
| Audio In | No |
| Audio Out | Stereo Mini Jack |
| RS232 In | Yes |
| RJ45 (LAN) | Yes |
| WiFi | Yes |
| Bluetooth | Yes |
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption (On Mode) | 38.5W |
| Power Consumption (Sleep Mode) | 0.5W |
| Set Dimensions (W × H × D) | 547.9 × 334.4 × 34.6 mm |
| Package Dimensions | 620 × 419 × 122 mm |
| Operating Temperature | 0°C – 40°C |
| Humidity | 10 – 80% (non-condensing) |
| VESA Mount | 100 × 100 mm |
| Frame Material | Non-Glossy |
| Touch Support | Yes |
| Touch Technology | Capacitive |
| Mount Included | No |
| Stand Included | No |
| OS Version | Tizen 7.0 |
| Flash Memory | 8 GB |
| EMC Certification | FCC, KCC, CE, VCCI, CCC, BSMI, C-Tick, GOST (Class B) |
| Safety Certification | IEC60950-1, EN60950-1, GB4943.1-2011, UL, SASO, BIS, NOM, IRAM, EAC, INMETRO, BSMI, RCM |
