Ubiquiti Dream Machine Pro Max Switch, 8x GbE RJ45 & 1x 10G SFP+ LAN Ports, Up to 5Gbps IDS/IPS Throughput, 1.3" Touchscreen, Quad-Core ARM Cortex-A57 Dream Machine Pro Max

Ubiquiti UniFi Dream Machine Pro Max  10G Cloud Gateway, 5 Gbps IDS/IPS, Redundant NVR Storage  UDM-PRO-MAX-EU

The UniFi Dream Machine Pro Max (UDM-PRO-MAX) is a high-performance 10G cloud gateway and network controller engineered for large enterprises, data-intensive environments, and mission-critical UniFi deployments.

It supports 200+ UniFi devices, 2,000+ concurrent clients, delivers up to 5 Gbps IDS/IPS throughput, and includes integrated redundant NVR storage for enterprise-grade reliability.

Housed in a 1U rack-mount aluminium chassis, the UDM-Pro Max combines advanced routing, next-generation security, SD-WAN, VPN, and UniFi OS applications in one powerful platform.

Key Features

• Supports 200+ UniFi Devices & 2,000+ Clients

• Up to 5 Gbps IDS/IPS Routing Throughput

• 10G Networking Ready

  • (1) × 10G SFP+ WAN

  • (1) × 10G SFP+ LAN

• (8) × GbE RJ45 LAN Ports

• Integrated Redundant NVR Storage

  • 128 GB Internal SSD + eMMC

• Quad-Core ARM Cortex-A57 @ 2.0 GHz

• 8 GB DDR4 RAM

• 1.3” Touchscreen LCM Display

• Redundant Power Support (USP-RPS)

• License-Free SD-WAN & Advanced VPN

• Rack-Mount 1U Enterprise Design

Enterprise-Grade Performance & Security

Designed for high-traffic networks, the UDM-Pro Max delivers full security at multi-gig speeds:

• Application-Aware Stateful Firewall

• Signature-Based IDS / IPS

• Content, Country, Domain & Ad Filtering

• VLAN & Subnet-Based Traffic Segmentation

• DPI & Traffic Identification

All while maintaining up to 5 Gbps throughput, even with IDS/IPS enabled.

Advanced WAN, SD-WAN & VPN

Built for multi-site enterprises and ISPs:

• Redundant WAN with Load Balancing & Failover

• License-Free SD-WAN

• VPN Support

  • WireGuard

  • OpenVPN (Server & Client)

  • L2TP

  • Site-to-Site VPN

• Policy-Based WAN & VPN Routing

• LTE Backup Support

• Internet Quality & Outage Reporting

Integrated Enterprise NVR

The UDM-Pro Max includes integrated and redundant storage, allowing it to act as a UniFi Protect NVR without external hardware:

• Internal 128 GB SSD

• 32 GB eMMC

• Designed for high-availability video recording

• Ideal for large camera deployments

Networking Interfaces

LAN

• (8) × 1 GbE RJ45

• (1) × 10G SFP+

WAN

• (1) × 2.5 GbE RJ45

• (1) × 10G SFP+

Hardware Specifications

• CPU: Quad-Core ARM Cortex-A57 @ 2.0 GHz

• Memory: 8 GB DDR4

• Storage:

  • 128 GB Integrated SSD

  • 32 GB eMMC

• Power Supply: Internal AC/DC 100W

• Redundant Power: USP-RPS DC Input

• Max Power Consumption: 100 W

Physical & Environmental

• Form Factor: 1U Rack-Mount

• Dimensions: 442.4 × 43.7 × 285.6 mm

• Weight: 4.7 kg

• Operating Temp: -10°C to 40°C

• Humidity: 5–95% (Non-condensing)

• ESD Protection: ±15 kV Air / ±8 kV Contact

Management & Display

• 1.3” Touchscreen LCM

• UniFi Network Web & Mobile App

• Ethernet & Bluetooth Management

• Real-Time Status, Alerts & Performance Metrics

Certifications

• CE

• FCC

• IC
