Product Description
Ubiquiti U7 Pro Tri-Band Wi-Fi 7 Access Point | 2.4GHz / 5GHz / 6GHz | Up to 9.3 Gbps | U7-Pro
The Ubiquiti UniFi U7 Pro is a next-generation, ceiling-mounted Wi-Fi 7 access point engineered for high-density and large-scale environments.
With tri-band connectivity (2.4 GHz, 5 GHz, and 6 GHz), Wi-Fi 7 (802.11be) support, and the ability to handle 300+ concurrent devices, the U7 Pro delivers ultra-fast, low-latency, and interference-free wireless performance.
Designed for enterprises, campuses, hotels, offices, and demanding commercial deployments, the U7 Pro ensures seamless connectivity, advanced security, and centralized management through the UniFi Network Application.
Key Features
Wi-Fi 7 (802.11be) Access Point
Up to 9.3 Gbps Total Wireless Throughput
Tri-Band Operation: 2.4 GHz / 5 GHz / 6 GHz
Supports 300+ Concurrent Clients
6 Spatial Streams (2×2 per band)
2.5GbE Ethernet Port with PoE+
WPA3 Enterprise-Grade Security
Guest Traffic Isolation
Wall & Ceiling Mounting Kit Included
Fully Managed via UniFi Network
Built for High-Density Environments
The U7 Pro leverages the 6 GHz band to minimize congestion and interference, ensuring consistent performance even in crowded wireless environments.
Advanced QoS, VLAN support, and per-user rate limiting help maintain optimal performance for critical applications such as video conferencing, cloud services, and real-time collaboration.
Enterprise-Grade Security & Management
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
VLAN (802.1Q) support
Guest traffic isolation
Centralized configuration, monitoring, and updates via UniFi Network
Specifications
Mechanical
| Item | Specification |
| Dimensions | Ø206 × 46 mm (Ø8.1 × 1.8") |
| Weight | 680 g (1.5 lb) |
| Enclosure Material | Polycarbonate, Metal |
| Mount Material | Stainless Steel (SUS304), Galvanized Steel (SGCC) |
| Mounting | Wall / Ceiling (Included) |
Hardware
| Item | Specification |
| Networking Interface | 1 × 1/2.5 GbE RJ45 |
| Management Interface | Ethernet |
| Power Method | PoE+ |
| Power Supply | UniFi PoE Switch |
| Supported Voltage Range | 44 – 57V DC |
| Max Power Consumption | 21 W |
| LEDs | White / Blue |
| Button | Factory Reset |
Wireless Performance
| Band | Throughput | MIMO | Max TX Power | Antenna Gain |
| 2.4 GHz | 688 Mbps | 2×2 | 22 dBm | 4 dBi |
| 5 GHz | 2882 Mbps | 2×2 | 26 dBm | 6 dBi |
| 6 GHz | 5765 Mbps | 2×2 | 23 dBm | 5.8 dBi |
Total Aggregate Throughput: Up to 9.3 Gbps
Software & Wireless Standards
| Feature | Details |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax/be |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| Concurrent Clients | 300+ |
Supported Data Rates
Wi-Fi 5 (802.11ac): up to 1.7 Gbps
Wi-Fi 6 / 6E (802.11ax): up to 2.4 Gbps
Wi-Fi 7 (802.11be): up to 5.7 Gbps (EHT, up to 320 MHz)
Environment & Certifications
| Item | Specification |
| Operating Temperature | -30°C to 60°C (-22°F to 140°F) |
| Operating Humidity | 5% – 95% (Non-condensing) |
| Certifications | CE, FCC, IC |
