Ubiquiti U7 Long-Range WiFi 7 Access Point, 5 Spatial Streams, 2.5GbE, 300+ Clients | U7-LR
The Ubiquiti UniFi U7 Long-Range (U7-LR) is a high-performance WiFi 7 access point designed to deliver extended coverage, high capacity, and ultra-stable wireless connectivity in demanding environments. Built on the latest WiFi 7 (802.11be) standard, it combines long-range signal strength, multi-gigabit uplink, and enterprise-grade roaming and security.
With 5 spatial streams, 3×3 MU-MIMO on 5 GHz, and 2×2 MU-MIMO on 2.4 GHz, the U7-LR supports 300+ concurrent clients while delivering combined wireless speeds of up to 4.3 Gbps. Its 2.5GbE uplink ensures maximum performance for modern high-speed networks.
Key Features
WiFi 7 (802.11be) Long-Range Access Point
Up to 4.3 Gbps Wireless Data Rates
5 Spatial Streams
300+ Concurrent Client Support
Extended Coverage up to 160 m² (1,750 ft²)
2.5GbE High-Speed Uplink
3×3 MU-MIMO on 5 GHz
Advanced Roaming & Mesh Capabilities
Enterprise-Grade Security & Guest Access
Ceiling or Wall Mount Installation
Managed via UniFi Network & Mobile Apps
Long-Range WiFi 7 Performance
The U7-LR is optimized for wide-area coverage and high-density usage, making it ideal for large spaces such as offices, campuses, hotels, warehouses, and enterprise floors.
5 GHz: up to 4.3 Gbps (160 MHz bandwidth)
2.4 GHz: up to 688 Mbps
High transmit power for extended reach and stable connections
High-Capacity Client Handling
Designed for environments with heavy device usage, the U7-LR efficiently handles:
300+ connected devices
Band steering and load balancing
AI-assisted radio management
Seamless roaming across UniFi APs
Enterprise Networking & Security
The U7-LR supports advanced UniFi features including:
Fast roaming (802.11r / 802.11k / 802.11v)
Wireless meshing
Private Pre-Shared Keys (PPSK)
Dynamic VLAN assignment via RADIUS
WPA2 / WPA3 Enterprise security
RADIUS over TLS (RadSec)
Guest Access & Hotspot Features
Ideal for public and commercial deployments:
Guest network isolation
Custom captive portal with branding
Voucher-based and payment-based authentication
External portal server support
Client isolation & speed limiting
Technical Specifications
Mechanical
| Feature | Specification |
| Dimensions | Ø175.7 × 43 mm |
| Weight | 448 g |
| Enclosure | Polycarbonate & Aluminum Alloy |
| Mounting | Ceiling / Wall (Mount Included) |
Wireless Performance
| Feature | Specification |
| WiFi Standard | WiFi 7 (802.11be) |
| Spatial Streams | 5 |
| MIMO | 5 GHz: 3×3 MU-MIMO 2.4 GHz: 2×2 MU-MIMO |
| Max Data Rate | 5 GHz: 4.3 Gbps 2.4 GHz: 688 Mbps |
| Antenna Gain | 5 GHz: 6 dBi 2.4 GHz: 4 dBi |
| Max TX Power | 5 GHz: 27 dBm 2.4 GHz: 26 dBm |
| Coverage Area | 160 m² (1,750 ft²) |
| Max Clients | 300+ |
Networking & Power
| Feature | Specification |
| Ethernet Port | (1) × 2.5GbE RJ45 |
| Power Method | PoE |
| Voltage Range | 42.5–57V DC |
| Max Power Consumption | 14W |
Environment & Compliance
| Feature | Specification |
| Operating Temperature | -30°C to 50°C |
| Operating Humidity | 5–95% Non-Condensing |
| Certifications | CE, FCC, IC, Anatel |
| NDAA Compliant | Yes |
