Product Description
Ubiquiti U7 Outdoor UniFi WiFi 7 Access Point, 2.5GbE, Weatherproof, 200+ Clients | U7 Outdoor
The Ubiquiti UniFi U7 Outdoor is a rugged, all-weather WiFi 7 access point engineered to deliver high-speed, long-range wireless coverage in outdoor and semi-outdoor environments. Built on the latest WiFi 7 (802.11be) standard, it combines directional high-gain antennas, multi-gigabit uplink, and enterprise-grade UniFi management.
Designed for harsh conditions, the U7 Outdoor features an IPX6 weatherproof enclosure, integrated directional super antenna, and external omni antennas, making it ideal for courtyards, campuses, warehouses, factories, parking areas, and outdoor hospitality spaces.
Key Features
WiFi 7 (802.11be) Outdoor Access Point
Up to 4.3 Gbps Wireless Speed
4 Spatial Streams
200+ Concurrent Client Support
2.5GbE High-Speed Ethernet Uplink
Integrated Directional + External Omni Antennas
Software-Switchable Antenna Modes
IPX6 Weatherproof Design
PoE+ Powered
Wall, Ceiling & Pole Mounting Included
Managed via UniFi Network Application
High-Performance Outdoor WiFi 7
The U7 Outdoor delivers powerful wireless performance optimized for outdoor deployments:
5 GHz: up to 4.3 Gbps (240 MHz bandwidth)
2.4 GHz: up to 688 Mbps
High TX power for extended outdoor coverage
Software-switchable antenna behavior for flexible deployments
Advanced Antenna Design
Engineered for coverage flexibility:
Integrated Directional Antenna
12.5 dBi @ 5 GHz
8 dBi @ 2.4 GHz
External Omni Antennas (RP-SMA)
Beamwidth:
2.4 GHz: 90°
5 GHz: 45°
This design ensures strong, focused signal delivery while minimizing interference.
Enterprise-Grade Capacity & Roaming
Built for high-density outdoor environments:
Supports 200+ connected devices
Seamless roaming with UniFi networks
Band steering & load balancing
Wireless meshing support
Per-user rate limiting & QoS
Security & Guest Access
The U7 Outdoor supports full UniFi security features:
WPA2 / WPA3 / Enterprise / PPSK
Guest network isolation
VLAN tagging (802.1Q)
Captive portal support
Secure device isolation
Technical Specifications
Mechanical
| Feature | Specification |
| Dimensions | 170 × 208 × 54.5 mm |
| Weight | 1.2 kg |
| Enclosure | UV-stabilized polycarbonate & aluminum alloy |
| Mounting | Wall / Ceiling / Pole (25–60 mm) |
| Wind Survivability | 125 mph (200 km/h) |
| Weatherproof Rating | IPX6 |
Wireless Performance
| Feature | Specification |
| WiFi Standard | WiFi 7 (802.11be) |
| Spatial Streams | 4 |
| MIMO | 2×2 MU-MIMO (2.4 & 5 GHz) |
| Max Data Rate | 5 GHz: 4.3 Gbps 2.4 GHz: 688 Mbps |
| Max Clients | 200+ |
| Antenna Type | Directional internal + external omni |
| Antenna Gain | 5 GHz: 12.5 dBi (dir) / 4 dBi (omni) 2.4 GHz: 8 dBi (dir) / 3 dBi (omni) |
Networking & Power
| Feature | Specification |
| Ethernet | (1) × 1/2.5 GbE RJ45 |
| Power Method | PoE+ |
| Voltage Range | 42.5–57V DC |
| Max Power Consumption | 19W |
Environment & Compliance
| Feature | Specification |
| Operating Temperature | -30°C to 60°C |
| Operating Humidity | 5–95% Non-Condensing |
| Certifications | CE, FCC, IC |
| Management | UniFi Network (v8.3+) |
