Product Description
Ubiquiti UniFi Pro Aggregation – Layer 3 25G/10G SFP Switch (USW-Pro-Aggregation)
The UniFi Pro Aggregation (USW-Pro-Aggregation) from Ubiquiti is a high-performance Layer 3 aggregation switch built to serve as the backbone of modern enterprise, campus, and data-center networks. Featuring (28) 10G SFP+ ports and (4) 25G SFP28 ports, it delivers massive uplink capacity for core-to-distribution and distribution-to-access aggregation—while remaining simple to operate through the UniFi Network platform.
With an industry-leading 760 Gbps switching capacity and 565.44 Mpps forwarding rate, the USW-Pro-Aggregation handles east-west traffic, virtualization backbones, and high-density AP uplinks without bottlenecks. A 1.3" LCM touchscreen provides instant visibility into system health and link status, and SmartPower RPS support adds power redundancy for mission-critical deployments.
Key Highlights
Layer 3 aggregation switch for enterprise cores
28× 10G SFP+ + 4× 25G SFP28 high-speed ports
760 Gbps switching capacity, 565.44 Mpps forwarding
1.3" LCM touchscreen for real-time insights
UniFi Network centralized management (web & mobile)
RPS support for enhanced power resilience
1U rack-mount, passive cooling, silver finish
Built for High-Bandwidth Network Cores
Massive Throughput, Zero Compromise
Aggregate dozens of 10G access/distribution links and uplink to 25G core paths with ease—ideal for Wi-Fi 6/6E/7 access layers, storage networks, and virtualization clusters.
Enterprise Layer 3 Features
Enable inter-VLAN routing, static routing, ACLs, and advanced traffic controls directly on the switch to reduce latency and offload routing from edge devices.
Simple, Unified Operations
Deploy, monitor, and scale using UniFi Network—with topology views, alerts, firmware updates, and remote management from anywhere.
Technical Specifications – UniFi Pro Aggregation (USW-Pro-Aggregation)
Hardware
| Item | Specification |
| Form Factor | 1U Rack-mount |
| Dimensions | 442 × 285 × 44 mm |
| Weight | 4.3 kg (without brackets) |
| Enclosure | SGCC steel |
| Display | 1.3" LCM touchscreen |
| Cooling | Passive |
| Management | Ethernet In-Band |
Interfaces
| Type | Ports |
| 10G | 28× SFP+ |
| 25G | 4× SFP28 |
Performance
| Metric | Value |
| Switching Capacity | 760 Gbps |
| Forwarding Rate | 565.44 Mpps |
| Non-Blocking | Yes |
Power
| Item | Specification |
| Input | Universal AC 100–240V, 50/60 Hz |
| Redundancy | USP-RPS DC input (SmartPower RPS, sold separately) |
| Power Supply | Internal AC/DC |
| Max Consumption | Low-power design (no PoE) |
Software & Features
| Category | Details |
| Layer 3 | Inter-VLAN routing, static routes |
| Layer 2 | VLANs, LACP, STP/RSTP, ACLs |
| Monitoring | Touchscreen status, UniFi analytics |
| Management App | UniFi Network (v5.10.5+) |
Environment & Compliance
| Item | Specification |
| Operating Temp | −5°C to 40°C |
| Humidity | 10–90% non-condensing |
| Certifications | CE, FCC, IC |
