Ubiquiti UniFi U6 Enterprise (U6-E) – WiFi 6E Tri-Band Enterprise Access Point
The UniFi U6 Enterprise (U6-E) from Ubiquiti is a high-density, enterprise-grade WiFi 6E access point engineered for demanding environments that require extreme capacity, speed, and reliability. Featuring tri-band operation (2.4 / 5 / 6 GHz), 10 spatial streams, and a 2.5GbE PoE+ uplink, the U6-E delivers up to 10.2 Gbps aggregate throughput and supports 600+ concurrent clients—ideal for campuses, offices, hotels, and large public venues.
With 4×4 MU-MIMO on both 6 GHz and 5 GHz (plus 2×2 on 2.4 GHz), 160 MHz channels, and advanced roaming and radio management, the U6-E ensures seamless, low-latency connectivity across bands. Enterprise security features like WPA3, Dynamic VLAN, RADIUS over TLS, and rich guest portal options make it a complete, future-ready solution.
Key Highlights
WiFi 6E (802.11ax) with dedicated 6 GHz spectrum
10 spatial streams (4×4 @ 6 GHz, 4×4 @ 5 GHz, 2×2 @ 2.4 GHz)
Up to 10.2 Gbps aggregate throughput
2.5GbE PoE+ uplink for high-speed backhaul
600+ clients, optimized for high-density deployments
WPA3 & enterprise security, advanced guest access
Ceiling or wall mount (Pro mount included)
Built for High-Density, Multi-Band Performance
True Tri-Band WiFi 6E
Unlock the clean 6 GHz band to reduce congestion and deliver ultra-low latency for modern devices, while maintaining powerful 5 GHz and reliable 2.4 GHz coverage.
Enterprise Capacity & Roaming
Advanced features—band steering, 802.11k/v/r fast roaming, Passpoint 2.0, and advanced radio management—keep users connected smoothly as they move.
Secure & Flexible Access
From PPSK and Dynamic VLANs to captive portals, vouchers, and external payment authentication, the U6-E adapts to any enterprise or public-access scenario.
Technical Specifications – UniFi U6 Enterprise (U6-E)
Hardware
| Item | Specification |
| Dimensions | Ø220 × 48 mm |
| Weight | 960 g (AP) / 1.1 kg (with mount) |
| Mounting | Ceiling / Wall (Pro mount included) |
| Enclosure | Polycarbonate & Aluminum |
| Power | PoE+, 44–57V DC |
| Max Power Draw | 22W |
| Uplink | 1× 1/2.5 GbE RJ45 |
Wireless Performance
| Band | MIMO | Max Rate | Antenna Gain | TX Power |
| 6 GHz | 4×4 DL/UL MU-MIMO | 4.8 Gbps (160 MHz) | 6 dBi | 26 dBm |
| 5 GHz | 4×4 DL/UL MU-MIMO | 4.8 Gbps (160 MHz) | 5.3 dBi | 26 dBm |
| 2.4 GHz | 2×2 DL/UL MU-MIMO | 573.5 Mbps (40 MHz) | 3.2 dBi | 22 dBm |
Spatial Streams: 10
Coverage Area: ~140 m² (1,500 ft²)
Max Clients: 600+
Channel Widths: 20 / 40 / 80 / 160 MHz
Max BSSIDs: 8 per radio
Features & Security
| Category | Details |
| Roaming & RRM | Band steering, 802.11k/v/r, advanced radio mgmt |
| Meshing | Yes |
| Guest Access | Captive portal, vouchers, payment auth, external portals |
| Security | WPA3, PPSK, client isolation, RADIUS over TLS |
| Networking | Dynamic VLAN, speed limiting, WiFi schedules |
| Management | UniFi Network (v6.0.45+), Ethernet & Bluetooth |
Compliance & Environment
| Item | Specification |
| Certifications | CE, FCC, IC, Anatel |
| NDAA | Compliant |
| Operating Temp | −30°C to 60°C |
| Humidity | 5–95% non-condensing |
| Frequencies | 2.4 / 5 / 6 GHz (US/CA & Worldwide variants) |
